Powder Bed Fusion Additive Manufacturing
High quality powder bed fusion additive manufacturing for custom metal and plastic parts
Powder Bed Fusion 3D Printing Technologies
Compare Powder Bed Fusion 3D Printing Technologies
| Materials | Max Part Size | Min Feature Size | Tolerances | |
|---|---|---|---|---|
| Metal 3D Printing | Aluminum Stainless Steel (17-4, 316L) Titanium Inconel Cobalt Chrome |
9.6 in. x 9.6 in. x 13.0 in X Line: 31.5 in. x 15.7 in. x 19.7 in. |
0.006 in. | ±0.003 in |
| Selective Laser Sintering | Nylons Polypropylene TPU |
19 in. x 19 in. x 17 in. | 0.030 in. | ±0.010 in. |
| Multi Jet Fusion | Nylons | 11.1 in. x 14.9 in. x 14.9 in. | 0.020 in. | ±0.012 in. |
| Materials | Max Part Size | Min Feature Size | Tolerances | |
|---|---|---|---|---|
| Metal 3D Printing | Aluminum Stainless Steel (17-4, 316L) Titanium Inconel Cobalt Chrome |
245mm x 245mm x 330mm X Line: 400mm x 800mm x 500mm | 0.1524mm | ±0.076mm |
| Selective Laser Sintering | Nylons Polypropylene TPU |
482mm x 482mm x 431mm | 0.762mm | ± 0.254mm |
| Multi Jet Fusion | Nylons | 281mm x 378mm x 378mm | 0.508mm | ±0.305mm |
Compare Powder Bed Fusion 3D Printing Materials
| Material | Process | Color | Tensile Strength | Tensile Modulus | Elongation |
|---|---|---|---|---|---|
| PA 12 White (PA 650) |
SLS | White |
7.25 ksi 50.0 MPa |
290 ksi 2,000 MPa |
11% |
| PA 12 Black | MJF | Black |
7.1 psi 49 MPa |
276 ksi 1,900 MPa |
8.5% |
| PA 11 Black (PA 850) |
SLS | Black |
7.54 ksi 52 MPa |
261 ksi 1,800 MPa |
30% |
| PA 12 Mineral-Filled (PA620-MF) | SLS | Light Gray |
5.51 ksi 38 MPa |
450 ksi 3,100 MPa |
3% |
| PA 12 40% Glass-Filled (PA 614-GS) |
SLS | White |
7.25 ksi 50MPa |
522 ksi 3,600 MPa |
5% |
| PA 12 40% Glass-Filled Black | MJF | Black |
4.35 ksi 30 MPa |
508 ksi 3,500 MPa |
8.5% |
| Polypropylene Natural | SLS | White |
2.61 ksi 18 MPa |
123 ksi 848 MPa |
15% |
| TPU 70-A | SLS | White |
580 psi 4.0 MPa |
7,300 psi 50.33 MPa |
210% |
| Materials | Resolution | Condition | Ultimate Tensile Strength | Yield Stress | Elongation | Hardness |
|---|---|---|---|---|---|---|
| Stainless Steel (17-4 PH) |
20 μm | Solution & Aged (H900) |
199 ksi 1,372 MPa |
178 ksi 1,227 MPa |
10% | 42 HRC |
| 30 μm | Solution & Aged (H900) |
198 ksi 1,365 MPa |
179 ksi 1,234 MPa |
13% | 42 HRC | |
| Stainless Steel (316L) |
20 μm | Stress Relieved |
82 ksi 565 MPa |
56 ksi 386 MPa |
78% | 90 HRB |
| 30 μm | Stress Relieved |
85 ksi 586 MPa |
55 ksi 379 MPa |
75% | 88 HRB | |
| Aluminum (AlSi10Mg) |
20 μm | Stress Relieved |
39 ksi 268 MPa |
26 ksi 180 MPa |
15% | 42 HRB |
| 30 μm | Stress Relieved |
50 ksi 345 MPa |
33 ksi 228 MPa |
8% | 59 HRB | |
| 40 μm | Stress Relieved |
43 ksi 296 MPa |
27 ksi 186 MPa |
10% | 50 HRB | |
| Cobalt Chrome (Co28Cr6Mo) |
20 μm | As Built |
182 ksi 1,255 MPa |
112 ksi 772 MPa |
17% | 39 HRC |
| 30 μm | As Built |
176 ksi 1,213 MPa |
119 ksi 820 MPa |
14% | 38 HRC | |
| Inconel 718 | 20 μm | Stress Relieved |
143 ksi 986 MPa |
98 ksi 676 MPa |
36% | 33 HRC |
| 30 μm | Stress Relieved |
144 ksi 993 MPa |
91 ksi 627 MPa |
39% | 30 HRC | |
| 30 μm | Solution & Aged per AMS 5663 |
208 ksi 1434 MPa |
175 ksi 1,207 MPa |
18% | 46 HRC | |
| 60 μm | Stress Relieved |
139 ksi 958 MPa |
83 ksi 572 MPa |
40% | 27 HRC | |
| 60 μm | Solution & Aged per AMS 5663 |
201 ksi 1386 MPa |
174 ksi 1,200 MPa |
19% | 45 HRC | |
| Titanium (Ti6Al4V) |
20 μm | Stress Relieved |
153 ksi 1055 MPa |
138 ksi 951 MPa |
15% | 35 HRC |
| 30 μm | Stress Relieved |
144 ksi 993 MPa |
124 ksi 855 MPa |
18% | 33 HRC |
