Design Guidelines: PolyJet

Our basic guidelines for PolyJet include important design considerations to help improve part manufacturability, enhance cosmetic appearance, and reduce overall production time.


Size

Maximum Dimensions

NORMAL RESOLUTION 19.3 in. x 15.4 in. x 7.9 in.
NORMAL RESOLUTION 490mm x 390mm x 200mm

Accuracy

Layer Thickness

NORMAL RESOLUTION 0.00118 in.
NORMAL RESOLUTION 30 microns

Minimum Feature Size

NORMAL RESOLUTION 0.012 in.
NORMAL RESOLUTION 0.3mm

For well-designed parts, tolerances of ±0.005 (0.1mm) for the first inch plus ±0.001 in./in. (0.001mm/mm) for each additional inch can typically be achieved. Note that tolerances may change depending on part geometry.

Minimum free-standing wall or feature is 0.030 in. (0.76mm). Holes, channels, and slots less than 0.030 in (0.76mm) in diameter/width will not form; maximum length-to-width aspect ratio is 4:1.


Design Essentials for 3D Printing

The 3D Printing Essentials reference guide offers guidelines and key considerations when designing for industrial 3D printing processes.

DOWNLOAD >

3D Printing Surface Finish Guide

Download this quick reference guide that looks at all of your surface finish options across our six additive manufacturing technologies.

DOWNLOAD >



Materials

PolyJet provides the ability to choose a desired hardness or combine material properties into a single build, which makes it ideal for prototyping overmolding parts. Shore A hardnesses of 30A, 40A, 50A, 60A, 70A, 85A, 95A, and rigid are available in these colors:

  • Digital Clear / Translucent

  • Digital Black

  • Digital White

VIEW MATERIALS >


Equipment

We use multiple additive machines that offer large build sizes, accurate parts, and quick production times. Our PolyJet equipment consists of Objet260 Connex3 and Objet350 Connex3 machines.
